HL301 Silver Brazing Rod (10% and 15%)
HL301 is a silver brazing rod supplied to GB/T 10046 in 10% and 15% silver content. It joins copper, copper alloys and steel by brazing rather than by fusion welding, so the base metal is not melted and dissimilar pairs can be joined without the cracking that fusion would bring. It is used in automotive assembly and light fabrication.
Status
Datasheet available on request






Description
Silver brazing rod supplied in 10% and 15% silver content, for joining copper, copper alloys and steel.
Welding positions, current range, deposition data and procedure notes are provided with the datasheet. Ask us for the grade you are specifying.
- Packing
- 5kg/box
- Standard
- GB/T 10046
- Application
- Automotive Manufacturing Welding
- Material
- Silver
- Form / model
- Silver welding rods
- Welding current
- /
- Operating temperature
- 645℃ - 740℃(1161℉-1332℉)
- MOQ
- 1kg
- Selling unit
- Single item
- Single gross weight
- 2.000 kg
- Single package size
- 55X20X20 cm
Lead time
- 1 - 1
- 15 days
- 2 - 100
- 30 days
What base metals can silver brazing rod join?
Suitable for copper, brass, bronze, carbon steel, stainless steel and cemented carbide. Perfect for dissimilar-metal brazing such as copper-to-steel.
What are the standard dimensions?
Standard length: 500mm. Available diameter range: 1.0-5.0mm. Custom-made length and diameter are acceptable for bulk orders.
What industries is this product mainly used in?
Widely used in HVAC refrigeration pipelines, valves, electrical components, auto spare parts, hydraulic fittings and carbide tool brazing.
