WT20 Thoriated Tungsten Electrode
WT20 is a thoriated tungsten electrode supplied to AWS A5.12 EWTh-2 and ISO 6848 WT20, carrying about 2% thorium oxide. The oxide addition improves electron emission, so the electrode starts more easily and carries more current than pure tungsten at the same diameter. Thorium is radioactive, which governs how the electrode is stored, ground and disposed of.
Status
Datasheet available on request








Description
Thoriated tungsten electrode for TIG welding.
Welding positions, current range, deposition data and procedure notes are provided with the datasheet. Ask us for the grade you are specifying.
- Standard
- AWS A5.12 EWTh-2 / ISO 6848 WT20
- Application
- Welding Work
- Material
- Tungsten
- Form / model
- WT20
- Packing
- 10 Pcs/ Plastic Box
- MOQ
- 200pcs
- Selling unit
- Single item
- Single gross weight
- 0.1 kg
- Single package size
- 25X5X3 cm
Lead time
- 1 - 500
- 15 days
- 501 - 10,000
- 30 days
What is WT20, and how do I identify it?
A thoriated tungsten electrode for TIG welding, supplied with a red tip. Red is the marking used for the thoriated grade, and this product is listed as a red-tipped thoriated tungsten electrode.
What size and length is it supplied in?
2.4 mm diameter by 175 mm long (0.09 in), packed 10 pieces to a plastic box. Each electrode weighs approximately 2.6 g.
Which shielding gas should it be used with?
Argon, or a mixed gas. It is a TIG (GTAW) electrode and is used in the torch, not consumed into the weld.
